SWSP138 series hammer mill
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Description
The crushing chamber achieves a true droplet shape, with a unique air intake method to avoid circulation during the crushing process; A "U" - shaped secondary striking groove is installed at the bottom of the crushing chamber to significantly increase production; Quick opening fully open operating door, elastic screening mechanism, convenient for maintenance and replacement of screening plates.
★Adopting imported "NSK" bearings to ensure service life, the nylon rod type coupling transmission does not experience large displacement, effectively avoiding bearing heating phenomenon.
★The rotor undergoes precise dynamic balance verification, fully optimizing the arrangement of hammer blades to ensure smoother operation, lower noise, and more ideal performance.
★The specially designed "mountain" shaped secondary crushing structure effectively changes the trajectory of material movement, increasing production by 25% year-on-year;
★A movable fully open operating door equipped with a linked screening mechanism, making operation and maintenance easier.
★By adjusting, coarse crushing, fine crushing, and fine crushing can be achieved, making one machine versatile.
★Used for high-end livestock and poultry feed, aquatic feed, as well as alcohol factories, citric acid factories, etc.
★Adopting imported "NSK" bearings to ensure service life, the nylon rod type coupling transmission does not experience large displacement, effectively avoiding bearing heating phenomenon.
★The rotor undergoes precise dynamic balance verification, fully optimizing the arrangement of hammer blades to ensure smoother operation, lower noise, and more ideal performance.
★The specially designed "mountain" shaped secondary crushing structure effectively changes the trajectory of material movement, increasing production by 25% year-on-year;
★A movable fully open operating door equipped with a linked screening mechanism, making operation and maintenance easier.
★By adjusting, coarse crushing, fine crushing, and fine crushing can be achieved, making one machine versatile.
★Used for high-end livestock and poultry feed, aquatic feed, as well as alcohol factories, citric acid factories, etc.
|
Main Technical and Performance Index Parameter Table |
||||||
|
Model specifications |
SWSP138x45E |
SWSP138x65E |
SWSP138x85E |
|||
|
Motor power (KW) |
90 |
110 |
110 |
132 |
132 |
160 |
|
Feeder motor power（kw） |
1.5 |
1.5 |
1.5 |
1.5 |
2.2 |
2.2 |
|
Mesh size (mm) |
0.6-8 |
0.6-8 |
0.6-8 |
0.6-8 |
0.6-8 |
0.6-8 |
|
Capacity (t/h) (3MM) |
2.5-14 |
3.0-15 |
3.0-17 |
3.0-20 |
4.0-25 |
5.0-28 |
