HMCL350 series pellet mill
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Description
★The main transmission adopts high-precision gear transmission, and the ring die adopts a quick release clamp type, which increases the output by about 20% compared to belt transmission.
★The transmission part of the whole machine uses high-quality bearings and oil seals from Switzerland and Japan to ensure efficient, stable, and low-noise transmission.
★The feeding adopts variable frequency speed regulation, which can effectively prevent uneven feeding caused by unstable voltage.
★All stainless steel extended and thickened strong quenching and tempering device, equipped with a large opening door for cleaning, and the steam inlet method has been changed from traditional radial inlet to axial inlet.
★The internationally advanced compensating snake shaped spring coupling has a novel, compact, safe, low-noise, and low fault performance.★High performance permanent magnet iron suction device.
Adopting internationally advanced steam pipeline systems, imported pressure reducing valves, and steam water separators to ensure the quality of quenched and tempered steam.
★All stainless steel door cover and inclined groove, with a stretching cutter with scale lines, making the cutter adjustment convenient and reliable.
★All kinds of safety overload protection devices and warning signs are complete.
★The transmission part of the whole machine uses high-quality bearings and oil seals from Switzerland and Japan to ensure efficient, stable, and low-noise transmission.
★The feeding adopts variable frequency speed regulation, which can effectively prevent uneven feeding caused by unstable voltage.
★All stainless steel extended and thickened strong quenching and tempering device, equipped with a large opening door for cleaning, and the steam inlet method has been changed from traditional radial inlet to axial inlet.
★The internationally advanced compensating snake shaped spring coupling has a novel, compact, safe, low-noise, and low fault performance.★High performance permanent magnet iron suction device.
Adopting internationally advanced steam pipeline systems, imported pressure reducing valves, and steam water separators to ensure the quality of quenched and tempered steam.
★All stainless steel door cover and inclined groove, with a stretching cutter with scale lines, making the cutter adjustment convenient and reliable.
★All kinds of safety overload protection devices and warning signs are complete.
|
Main Technical and Performance Index Parameter Table |
|||||||
|
Model |
HMCL-320 |
HMCL-350 |
HMCL-400 |
HMCL-420 |
HMCL-508 |
HMCL-578 |
HMCL-678 |
|
Main motor power(kw) |
37 |
55 |
90 |
110 |
132/160 |
160/180 |
180/200 |
|
Capacity(t/h) |
2-5 |
2-8 |
3-12 |
4-15 |
6-20 |
8-25 |
10-28 |
|
Feeder motor power(kw) |
0.75 |
0.75 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
|
Conditioner motor power(kw) |
2.2 |
2.2 |
5.5 |
5.5 |
7.5 |
7.5 |
7.5 |
|
Ring die diameter (mm): |
Φ320 |
Φ350 |
Φ400 |
Φ420 |
Φ508 |
Φ578 |
Φ678 |
|
Particle size (mm) |
Φ1.5-Φ12 |
Φ1.5-Φ12 |
Φ1.5-Φ12 |
Φ1.5-Φ18 |
Φ2.0-Φ18 |
Φ2.0-Φ18 |
Φ2.0-Φ18 |
